Type K Armored Thermocouple

●Temperature probe, diameter and length can be customized according to requirements
●Stainless steel fasteners, hexagonal pressing, locking probe
●Bendable wire guard spring to protect the lead wire from being broken
●Wire length can be customized
●Mini plugs, standard plugs, terminals, pins, bare wires, can be customized

Ask A Quote

Product Description

Performance Parameter

Performance Parameter
Product Name	Type K Armored Thermocouple
Index Number	K
Temperature Range	-40℃～1200℃(customizable)
Lead Material	Metal Shielded Wire
Lead Length	On-demand customization
Probe Diameter	0.25 mm / 0.5 mm / 0.8 mm / 1.0 mm (customizable)
Symphysis Material	nickel chromium +/ nickel silicon –
Connection Mode	Wiring mode Default U-shaped terminal (pin, bare wire, and in-line)

Armoured Wire Performance Parameter Table

Product Name	Designation	Graduated Mark	Casing Material	Outside Diameter	Reference Service Temperature
Nickel-Chromium – Nickel-Aluminum	KK	K	0Cr18Ni10Ti（SUS304) Mo2Ti（SUS316L）	0.5~1.0	400
				1.5~3.2	600
				4.0~8.0	800
			Cr15Ti（SUS310S) GH3030 GH3039 INCONEL600 INCOLOY800	0.5~1.0	500
				1.5~3.2	800
				4.0~6.4	900
				8.0~12.7	1000
Nickel-Chromium-Silicon – Nickel-Silicon	NK	N	0Cr18Ni10Ti（SUS304) Mo2Ti（SUS316L）	1.5~1.0	400
				1.5~3.2	600
				4.0~8.0	800
			Cr15Ti（SUS310S） GH3030 GH3039 INCONEL600 INCOLOY800	0.5~1.0	500
				1.5~3.2	800
				4.0~6.4	900
				8.0~12.7	1000
Nickel-Chromium – constantan	EK	E	0Cr18Ni10Ti（SUS304) Mo2Ti（SUS316L)	0.5~1.0	400
				1.5~3.2	500
				4.0~8.0	800
iron – constantan	JK	J	0C18Ni10Ti（SUS304) Mo2Ti（SUS316L)	1.0	300
				1.5~3.2	500
				4.0~8.0	800
copper – constantan	TK	T	0Cr18Ni10Ti（SUS304） Mo2Ti（SUS316L）	1.0	-200~100
				1.5~3.2	100~200
				4.0~8.0	100~350
platinum-rhodium 10 – platinum platinum-rhodium13 – platinum	SK RK	S R	Gh3030 INCONEL600 GH3039 GH747	2.0~4.8	1000
				5.0~6.4	1050
				8.0	1150
			铂铑6	2.0~6.4	1200
platinum-rhodium 30 – platinum-rhodium 6	BK	B	Gh3030 INCONEL600 GH3039 GH747	2.0~4.8	1000
				5.0~6.4	1080
				8.0	1180
